SF6 Gas Recovery Plant

  • Our company simplifies the recycling vehicle’s parts to create a portable SF6 gas recovery plant, making it easy to carry, transport, and combine for clear functionality.

Share to

Features of SF6 Gas Recovery Plant

The SF6 gas recovery plant serves those SF6 units and GIS composite units.

  1. The equipment can vacuum those SF6 units with GIS composite units and then fill SF6 gas.
  2. This kind of equipment can recover SF6 gas from these units, clean, compress, and store SF6 gas in the storage tank.
  3. The machine consists of a recycling system, filling system, vacuum system, purification system, and storage system.
  4. The machine can perform vacuum and vacuum measurements of itself and other devices.
  5. You have a variety of SF6 gas treatment equipment to choose from.

Usage of SF6 Gas Recovery Plant

  1. The SF6 gas recovery plant can recover SF6 gas.
  2. The equipment can dry and purify recovered SF6 gas.
  3. The machine can be used as a device for filling SF6 gas.
  4. This kind of equipment is a device for storing SF6 gas.
SF6 Gas Recovery Plant
SF6 Gas Recovery Plant

SF6 Gas Recovery Plant Specification

Type High pressure liquefaction, air cool, mobile
Working Environmental Temperature -10 ~ 40
Recovery Initial pressure 0.8
Final pressure (MPa) ≤0.05
Time to recover 1m3 gas(h/m) ≤0.5
Filling Initial pressure ≤133
Final pressure (MPa) 0.8
Time to recover 1m3 gas(h/m) ≤0.5
Time for pumping vacuum from 0.1Mpa to 133Pa(h/m) ≤1
Limit vacuum (Pa) ≤10
Gas purity after recovery SF6 (50KGS) Water content(PPM/V) ≤60
Oil content (PPM/W) ≤5
Dust(Micron ≤1
Storing Tank Storage method Liquid gas
Pressure (MPa) ≤5.0
Volume (L) 300
Liquid volume(Kg) 280
Liquefaction method High pressure liquefaction
Vaporization method Heating with electricity
Dry filter regeneration Vacuum heating re-activated
Power 380V 50Hz 3 Phase 4 Wire (based on your requirement)
Overall dimension mm
1600*1000*1900 (including the storing tank)
1600*1000*1200 (without the storing tank)
Total power (KW) ≤8

The machine size and weight will change slightly due to different configurations.
